Auto Tablet rejection during machine START & STOP and Random sampling device.
Powder Level monitoring device of the feed hoppers.
Technical Specifications: cCMP
Type
IPD II - 37
IPB II - 45
IPBB II - 55
IPBB II - 61
No. of stations
37
45
55
61
Type of tooling
D
B
BB
BB
Output tablets/hour *
53280 to 266400
64800 to 324000
79200 to 396000
87840 to 439200
Max. operating pressure (main)
10 Tons
6.5 Tons
6.5 Tons
6.5 Tons
Max. tablet diameter
23 mm (25mm on Demand)
16 mm
11.1 mm
11.1 mm
Max. depth of fill
20 mm
17 mm
17 mm
17 mm
Upper punch penetration
3.2 to 6 mm
3.2 to 6 mm
3.2 to 6 mm
3.2 to 6 mm
Power (total)
7 kW / 9.5 hp
7 kW / 9.5 hp
7 kW / 9.5 hp
7 kW / 9.5 hp
Main electric motor
5.5 kW / 7.5 hp, 1440 RPM, 415 V, 50 Hz, 3Ph
Force feeder motor (2 Nos.)
0.19 kW / 0.25 hp
Overall dimensions (cm)
147 X 140 X 187 H
Net weight
2500 kg
Case dimension (cm)
168 X 183 X 224 H
Gross Weight
2835 kg
* Depending upon the characteristic of material and shape & size of tablets.
NOTE : DUE TO CONTINIOUS IMPROVEMENTS IN THE MACHINERIES, SPECIFICATION OF THE MACHINERIES IS SUBJECT TO CHANGE WITHOUT ANY PRIOR NOTICE.
Also Available with
Bi - Layer (Two Layer)
attachment
